Saturn Astra I (2008-2009) right engine cooling fan Wiring diagrams
This page contains all the electrical diagrams for the component. right engine cooling fan, in which he is found in the car Saturn Astra I (2008-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right engine cooling fan (1 of 2)
2500 2501 5267 COMPUTER DATA LINES SYSTEM
BLU WIRE
BRN WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
DUAL FAN
ENGINE CONTROL MODULE (ECM)
ENGINE COOLANT LEVEL SWITCH
ENGINE COOLING FAN
FANS
FUSE 5
FUSE 6
GRN WIRE
HOT AT ALL TIMES
LEFT ENGINE COOLING FAN
LOGIC
RED/WHT WIRE
RED/YEL WIRE
RELAY
RELAY (DUAL
RIGHT ENGINE COOLING FAN
SINGLE FAN
UNDERHOOD FUSE BLOCK
WHT/BLK WIRE
Go to component -> Cooling fan circuit -> RIGHT ENGINE COOLING FAN
Wiring diagram right engine cooling fan (2 of 2)
10 59 (OR 335) (OR 473)
A/C COMPRESSOR CLUTCH
A/C REFRIGERANT PRESSURE SENSOR
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
DUAL FAN
ENGINE CONTROL MODULE (ECM)
ENGINE COOLING FAN
FUSE 20
FUSE 4
FUSE 5
FUSE 6
GRN WIRE
HOT AT ALL TIMES
LEFT ENGINE COOLING FAN (DUAL FAN)
LOGIC
RED/WHT WIRE
RED/YEL WIRE
RELAY
RELAY ENERGIZED
RIGHT ENGINE COOLING FAN
SINGLE FAN
UNDERHOOD FUSE BLOCK
WHT/BLK WIRE
YEL/RED WIRE
Go to component -> Manual a/c circuit (2 of 2) -> RIGHT ENGINE COOLING FAN
