Saturn Astra I (2008-2009) low speed gmlan ser data Wiring diagram
This page shows the only wiring diagram for the component.low speed gmlan ser data, which is found in the car Saturn Astra I (2008-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low speed gmlan ser data (1 of 1)
6 42 REAR DEF SW REAR DEF RLY CTRL
BLK WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DEFOG IND
DEFOG SWITCH
DRIVER OUTSIDE REARVIEW MIRROR
FUSE 11
FUSE 21
FUSE 3
GRN WIRE
HOT AT ALL TIMES
HVAC CONTROL ASSEMBLY
INSTRUMENT PANEL CLUSTER (IPC)
LOGIC
LOW SPEED GMLAN SER DATA
PASSENGER OUTSIDE REARVIEW MIRROR
REAR DEFROST RELAY
REAR FUSE BLOCK
REAR WINDOW DEFOGGER GRID
RED WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Defoggers circuit -> LOW SPEED GMLAN SER DATA
