Saturn Astra I (2008-2009) liftgate latch assembly Wiring diagrams
This page contains all the electrical diagrams for the component. liftgate latch assembly, in which he is found in the car Saturn Astra I (2008-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram liftgate latch assembly (1 of 2)
3 DOOR
3 DOOR 5 DOOR 1 6
5 DOOR
5 DOOR 3 DOOR 1 6
A/T
AUTOMATIC TRANSMISSION SHIFT LOCK CONTROL INDICATOR RELAY
BLK WIRE
BRN WIRE
CARGO LAMP
CIGAR LIGHTER
COURTESY/ READING LAMPS
DATA LINK CONNECTOR (DLC)
DOME LAMP
DOOR LOCK RELAY
DRIVER CUSHION HEATED SEAT ELEMENT
DRIVER DOOR LOCK
DRIVER HEATED SEAT CONTROL MODULE
DRIVER OUTSIDE REARVIEW MIRROR
DRIVER WINDOW MOTOR
DRIVER WINDOW SWITCH
FUEL LEFT LEFT PUMP, REAR REAR SENDER WINDOW WINDOW ASSEMBLY SWITCH MOTOR
HEADLAMP, PANEL DIMMER SWITCH
HVAC CONTROL MODULE
I/P COMPARTMENT LAMP
I/P TIRE MULTI- PRESSURE FUNCTION MODULE SWITCH
IGNITION LOCK PARK CYLINDER POSITION CONTROL SWITCH SWITCH
INSIDE REARVIEW MIRROR (ISRVM)
INSTRUMENT PANEL CLUSTER (IPC)
LEFT FRONT DOOR COURTESY LAMP
LEFT REAR DOOR LOCK
LEFT REAR SIDE MARKER LAMP
LEFT SUNSHADE
LIFTGATE LATCH ASSEMBLY
LIFTGATE LEFT RELEASE TAIL SWITCH LAMP
LOGIC
OVERHEAD CONSOLE COURTESY/ READING LAMPS
PASSENGER PASSENGER CUSHION HEATED HEATED SEAT CONTROL SEAT ELEMENT MODULE
REAR FUSE BLOCK
RED WIRE
RIGHT LICENSE LAMP
RIGHT REAR SIDE LEFT MARKER LICENSE LAMP LAMP
RIGHT SUNSHADE
RIGHT TAIL LAMP
STEERING COLUMN CONTROL MODULE
SUNROOF MOTOR
SUNROOF SHADE SWITCH
SUNROOF SWITCH
TRANSMISSION CONTROL MODULE (TCM)
W/ SPOILER, SUNROOF
W/O SPOILER, SUNROOF
WHT WIRE
WINDSHIELD OUTSIDE MOISTURE SENSOR
WINTER MODE SWITCH
YEL WIRE
Go to component -> Ground distribution circuit (2 of 2) -> LIFTGATE LATCH ASSEMBLY
Wiring diagram liftgate latch assembly (2 of 2)
Go to component -> Trunk release circuit -> LIFTGATE LATCH ASSEMBLY
