Saturn Astra I (2008-2009) lh lr brk turn lp sig lp sply sply volt volt Wiring diagram
This page shows the only wiring diagram for the component.lh lr brk turn lp sig lp sply sply volt volt, which is found in the car Saturn Astra I (2008-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lh lr brk turn lp sig lp sply sply volt volt (1 of 1)
5 DOOR 3 DOOR
BACKUP LAMP CIRCUIT
BLK WIRE
BRN WIRE
BRN/GRY WIRE
CENTER HIGH MOUNTED STOP LAMP
CHMSL SPLY VOLT
COMPUTER DATA LINES SYSTEM
FUSE 3
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT SIDE MARKER LAMP
LEFT LICENSE LAMP
LEFT REAR SIDE MARKER LAMP
LEFT TAIL LAMP
LF TURN SIG SW SIG
LH LR BRK TURN LP SIG LP SPLY SPLY VOLT VOLT
LICENSE SPLY VOLT SIG
LOGIC LOW SPD GMLAN SERIAL DATA
REAR FUSE BLOCK
RED WIRE
RF TURN SIG SW SIG
RH BRK LP SPLY VOLT
RIGHT FRONT SIDE MARKER LAMP
RIGHT LICENSE LAMP
RIGHT REAR SIDE MARKER LAMP
RIGHT TAIL LAMP
RR TURN SIG LP SPLY VOLT
STOP LAMP SW SIG
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> LH LR BRK TURN LP SIG LP SPLY SPLY VOLT VOLT
