Saturn Astra I (2008-2009) left front down sig Wiring diagram
This page shows the only wiring diagram for the component.left front down sig, which is found in the car Saturn Astra I (2008-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front down sig (1 of 1)
BLK WIRE
BRN WIRE
BRN/BLK WIRE
COMFORT CLOSE SIG
DK BLU/BRN WIRE
DK BLU/DK GRN WIRE
DOWN
DRIVER WINDOW MOTOR
DRIVER WINDOW SWITCH
FUSE 1
FUSE 23
FUSE 38
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT DOWN SIG
LEFT FRONT UP SIG
LEFT REAR DOWN SIG
LEFT REAR UP SIG
LEFT REAR WINDOW MOTOR
LEFT REAR WINDOW SWITCH
LOGIC
PASSENGER WINDOW MOTOR
PASSENGER WINDOW SWITCH
PPL/BRN WIRE
PPL/DK GRN WIRE
REAR FUSE BLOCK
RED WIRE
RIGHT FRONT DOWN SIG
RIGHT FRONT UP SIG
RIGHT REAR DOWN SIG
RIGHT REAR UP SIG
RIGHT REAR WINDOW MOTOR
RIGHT REAR WINDOW SWITCH
WHT/DK BLU WIRE
WHT/DK GRN WIRE
YEL/BRN WIRE
YEL/DK GRN WIRE
Go to component -> Power windows circuit -> LEFT FRONT DOWN SIG
