Saturn Astra I (2008-2009) left auxiliary audio sig 2 right auxiliary audio sig 2 Wiring diagram
This page shows the only wiring diagram for the component.left auxiliary audio sig 2 right auxiliary audio sig 2, which is found in the car Saturn Astra I (2008-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left auxiliary audio sig 2 right auxiliary audio sig 2 (1 of 1)
* - INFORMATION NOT AVAILABLE
ANTENNA
AUXILIARY AUDIO SCREEN 2
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CELLULAR TELEPHONE VOICE SIG
CENTER I/P SPEAKER
COAX ANTENNA
COMPUTER DATA LINES SYSTEM
DOWN
FRONT CENTER SPEAKER (-) BATT POSITIVE VOLT FRONT CENTER SPEAKER (+)
FUSE 35
GRN WIRE
HOT AT ALL TIMES
INFO
LEFT AUXILIARY AUDIO SIG 2 RIGHT AUXILIARY AUDIO SIG 2
LEFT FRONT
LEFT REAR SPEAKER
LOW REF
MUTE
RADIO
RED WIRE
RIGHT FRONT
RIGHT REAR
RIGHT STEERING WHEEL CONTROL SWITCH
SPEAKER
TWEETER SPEAKER
UNDERHOOD FUSE BLOCK
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM)
VIO/RED WIRE
VIO/WHT WIRE
W/ PREMIUM
WHT WIRE
WHT/BRN WIRE
YEL WIRE
YEL/BRN WIRE
YEL/WHT WIRE
Go to component -> Radio circuit -> LEFT AUXILIARY AUDIO SIG 2 RIGHT AUXILIARY AUDIO SIG 2
