Saturn Astra I (2008-2009) hi spd hi spd low low hi spd gmlan spd spd gmlan gmlan serial Wiring diagram
This page shows the only wiring diagram for the component.hi spd hi spd low low hi spd gmlan spd spd gmlan gmlan serial, which is found in the car Saturn Astra I (2008-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hi spd hi spd low low hi spd gmlan spd spd gmlan gmlan serial (1 of 1)
A/T
BLU WIRE
BRN WIRE
BRN/VIO WIRE
DATA LINK CONNECTOR (DLC)
DLC CLASS 2 SERIAL DATA
DRIVER INFORMATION CENTER (DIC)
ELECTRONIC BRAKE CONTROL MODULE (EBCM) (IF EQUIPPED)
ENGINE CONTROL MODULE
FUSE
GRN WIRE
GRN/WHT WIRE
HI SPD
HI SPD HI SPD LOW LOW HI SPD GMLAN SPD SPD GMLAN GMLAN SERIAL
HIGH SPEED GMLAN SERIAL DATA (+)
HIGH SPEED GMLAN SERIAL DATA BUS +
HOT AT ALL TIMES
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM)
LEFT VEHICLE COMMUNICATION INTERFACE MODULE (VCIM)
LO SPD
LOW SPEED GMLAN SERIAL DATA
M/T
MID SPEED GMLAN SERIAL DATA
POWER STEERING CONTROL MODULE (PSCM)
POWER STEERING CONTROL MODULE (ZF STEERING)
REAR FUSE LO SPD GMLAN GMLAN BLOCK SERIAL SERIAL DATA DATA
RED WIRE
RIGHT VEHICLE COMMUNICATION INTERFACE MODULE (VCIM)
STEERING COLUMN CONTROL MODULE
TIRE PRESSURE MODULE
TRANSMISSION CONTROL MODULE
WHT WIRE
YAW, LATERAL ACCELEROMETER SENSOR
YEL WIRE
Go to component -> Computer data lines circuit -> HI SPD HI SPD LOW LOW HI SPD GMLAN SPD SPD GMLAN GMLAN SERIAL
