Saturn Astra I (2008-2009) h spd gmlan + h spd gmlan - ign lck sw Wiring diagram
This page shows the only wiring diagram for the component.h spd gmlan + h spd gmlan - ign lck sw, which is found in the car Saturn Astra I (2008-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram h spd gmlan + h spd gmlan - ign lck sw (1 of 1)
B+ B+ GND
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 34
GRN WIRE
H SPD GMLAN + H SPD GMLAN - IGN LCK SW
HI SPEED GMLAN
HOT AT ALL TIMES
IGNITION LOCK CYLINDER CONTROL SWITCH
IGNITION SWITCH
KEY-IN IGNITION SWITCH
LOGIC
OFF
RED WIRE
RUN WIRE
STEERING COLUMN CONTROL MODULE
STEERING WHEEL THEFT DETERRENT LOCK
TRANSMISSION CONTROL MODULE (TCM)
UNDERHOOD FUSE BLOCK
WHT WIRE
Go to component -> Ignition lock solenoid circuit -> H SPD GMLAN + H SPD GMLAN - IGN LCK SW
