Saturn Astra I (2008-2009) frt fog lp sw sig Wiring diagram
This page shows the only wiring diagram for the component.frt fog lp sw sig, which is found in the car Saturn Astra I (2008-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram frt fog lp sw sig (1 of 1)
AUTO PARK HEAD
AUTO PARK OFF HEAD
BLU WIRE
BRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
FOG LAMP IND
FRONT FOG LAMP
FRT FOG LP SW SIG
GMLAN SERIAL DATA
GRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/GRN WIRE
HDLP LO BEAM
HDLP SW PRK LP SIG
HEADLAMP, PANEL DIMMER SWITCH
HIGH BEAM IND
HIGH BEAM SWITCH
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
LEFT FRONT FOG LAMP
LEFT HEADLAMP
LEFT HIGH BEAM HEADLAMP SOLENOID
LEFT LOW BEAM HEADLAMP
LF FOG LP SPLY VOLT
LH HDLP HI BEAM SPLY VOLT
LH HDLP LO BEAM SPLY VOLT
LO SPD
LOGIC
LOGIC FUSE 3
LOGIC FUSE LO SPD GMLAN GMLAN SERIAL SERIAL DATA DATA
OFF
REAR FUSE BLOCK
RED WIRE
RF FOG LP SPLY VOLT
RH HDLP HI BEAM SPLY VOLT
RH HDLP LO BEAM SPLY VOLT
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
RIGHT HIGH BEAM HEADLAMP SOLENOID
RIGHT LOW BEAM HEADLAMP
SIG GND
STEERING COLUMN CONTROL MODULE
SWITCH
UNDERHOOD FUSE BLOCK
WHT WIRE
YEL WIRE
Go to component -> Headlights circuit -> FRT FOG LP SW SIG
