Saturn Astra I (2008-2009) evap canister purge tac close tac close ignition control 4 ignition control 4 Wiring diagram
This page shows the only wiring diagram for the component.evap canister purge tac close tac close ignition control 4 ignition control 4, which is found in the car Saturn Astra I (2008-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram evap canister purge tac close tac close ignition control 4 ignition control 4 (1 of 1)
BLK WIRE
BLK/BRN WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CAMSHAFT POSITION (CMP) ACTUATOR SOLENOID EXHAUST VALVE
CAMSHAFT POSITION (CMP) ACTUATOR SOLENOID INTAKE VALVE
ENGINE CONTROL MODULE (ECM)
ENGINE COOLANT TEMPERATURE (ECT) SENSOR
ENGINE OIL LEVEL (EOL) SWITCH
ENGINE OIL PRESSURE (EOP) SWITCH
EVAP CANISTER PURGE TAC CLOSE TAC CLOSE IGNITION CONTROL 4 IGNITION CONTROL 4
EVAPORATIVE EMISSION (EVAP) CANISTER PURGE SOLENOID VALVE
FUEL INJECTORS
GRN/WHT WIRE
GRY/BLK WIRE
GRY/RED WIRE
IAT
INTAKE MANIFOLD TUNING (IMT) SOLENOID VALVE
MASS AIR FLOW (MAF)/INTAKE AIR TEMPERATURE (IAT) SENSOR
RED/BLU WIRE
THROTTLE ACTUATOR CONTROL (TAC) MODULE
YEL/BLK WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 1.8l vin 1 (4 of 4) -> EVAP CANISTER PURGE TAC CLOSE TAC CLOSE IGNITION CONTROL 4 IGNITION CONTROL 4
