Saturn Astra I (2008-2009) a/c request switch Wiring diagram
This page shows the only wiring diagram for the component.a/c request switch, which is found in the car Saturn Astra I (2008-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram a/c request switch (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 PPL
A/C REQUEST INDICATOR
A/C REQUEST SWITCH
AIR TEMPERATURE ACTUATOR
BLK WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLOWER MOTOR
BLOWER MOTOR RESISTOR ASSEMBLY
BLOWER MOTOR SWITCH
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
FUSE 14
FUSE 4
GRN WIRE
GRY WIRE
HOT AT ALL TIMES REAR FUSE BLOCK
HVAC CONTROL ASSEMBLY
INSTRUMENT PANEL CLUSTER (IPC)
LOGIC
LOW OFF
MODE ACTUATOR
MODE SWITCH
NCA WIRE
ORG/ WIRE
ORG/YEL WIRE
PPL
RECIR- CULATION INDICATOR
RECIR- CULATION SWITCH
RECIRCULATION ACTUATOR
RED WIRE
RELAY ENERGIZED
TEMPERATURE CONTROL SWITCH
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
Go to component -> Manual a/c circuit (1 of 2) -> A/C REQUEST SWITCH
