Saab 9000 I facelift (1991-1998) shift lock relay a/c system Wiring diagram
This page shows the only wiring diagram for the component.shift lock relay a/c system, which is found in the car Saab 9000 I facelift (1991-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram shift lock relay a/c system (1 of 1)
96-98
AIRBAG
ANTI-THEFT ALARM CONTROL MODULE
BLU WIRE
CLOCK
CONNECTOR FOR MOBILE PHONE
DASHBOARD ELECTRICAL DISTRIBUTION BOX (BEHIND GLOVE BOX)
DATA LINK CONNECTOR
DISTRIBUTION TERMINAL +15
FROM DASHBOARD ELECTRICAL DISTRIBUTION BOX (DIAGRAM 2 OF 3)
FROM IGNITION SWITCH (DIAGRAM 2 OF 3)
FRONT FOG LIGHT SWITCH
FUSE 1
FUSE 13
FUSE 29 FUSE 32
FUSE 30
FUSE 4
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
HEADLIGHT RELAY
IGNITION COIL MODULE
INSTRUMENT CLUSTER VEHICLE SPEED SENSOR
INSTRUMENT CLUSTER, EDU ELECTRONIC CONTROL MODULE, PICTOGRAM
INTERIOR LIGHTS TIME-DELAY RELAY
LEFT EXTERIOR, GLOVE BOX LIGHTS
LIGHT SWITCH
MOTRONIC/TRIONIC ENGINE CONTROL MODULES
OFF
PARK HEAD
PARK OFF HEAD
REAR DEFOGGER RELAY
REAR LAMPS FILAMENT MONITOR
RED WIRE
RIGHT EXTERIOR, LICENSE LIGHTS REAR FOG LIGHT SWITCH
SHIFT LOCK RELAY A/C SYSTEM
TCS CONTROL MODULE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 3) -> SHIFT LOCK RELAY A/C SYSTEM
