Saab 9000 I facelift (1991-1998) right front side reversing light Wiring diagram
This page shows the only wiring diagram for the component.right front side reversing light, which is found in the car Saab 9000 I facelift (1991-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front side reversing light (1 of 1)
4 DOOR
5 DOOR
A/T
A/T GEAR SELECTOR LEVER POSITION SWITCH (UNDER CENTER CONSOLE)
BACKUP LIGHT
BLK WIRE
DASHBOARD ELECTRICAL DISTRIBUTION BOX (BEHIND GLOVE BOX)
FUSE 16
FUSE 9
GRN WIRE
HOT AT ALL TIMES
HOT IN RUN
LEFT FRONT SIDE REVERSING LIGHT
LEFT TAILLIGHT ASSEMBLY
M/T
REAR LIGHT ASSEMBLY (CENTER OF TAILGATE)
RED WIRE
REVERSING LIGHT SWITCH (LEFT SIDE OF GEAR BOX)
RIGHT FRONT SIDE REVERSING LIGHT
RIGHT TAILLIGHT ASSEMBLY
TRIONIC ENGINE CONTROL MODULE (BEHIND RIGHT KICK PANEL)
WHT WIRE
Go to component -> Backup lamps circuit -> RIGHT FRONT SIDE REVERSING LIGHT
