Saab 9000 I facelift (1991-1998) right front door indicator Wiring diagram
This page shows the only wiring diagram for the component.right front door indicator, which is found in the car Saab 9000 I facelift (1991-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front door indicator (1 of 1)
AIRBAG CONTROL MODULE (BELOW CENTER CONSOLE)
AIRBAG WARNING INDICATOR
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAKE LIGHT SWITCH
BRN WIRE
BRN/WHT WIRE
CENTRAL LOCKING SYSTEM CONTROL MODULE (BEHIND FAR LEFT I/P,
CENTRAL WARNING LIGHT
DASHBOARD ELECTRICAL DISTRIBUTION BOX (BEHIND GLOVE BOX)
DRIVER'S DOOR AJAR SWITCH
ENGINE COMPARTMENT ELECTRICAL DISTRIBUTION BOX (FORWARD OF BATTERY)
ENGINE OIL PRESSURE SENSOR (FRONT OF ENGINE BLOCK)
EXTERIOR LIGHTS SYSTEM (BRAKE LIGHTS)
EXTERIOR LIGHTS SYSTEM (HIGH LEVEL BRAKE LIGHT)
FRONT LAMPS FILAMENT MONITOR (LEFT FRONT CORNER OF ENGINE COMPARTMENT)
FRONT LIGHT OUTAGE INDICATOR
FUSE 29 FUSE 30
FUSE 7
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HEADLIGHTS SYSTEM
HEADLIGHTS SYSTEM (HEADLIGHT RELAY)
HEADLIGHTS SYSTEM (LEFT HIGH BEAM)
HOT WITH LIGHTING SWITCH IN PARK
LEFT FRONT DOOR AJAR INDICATOR
LEFT REAR DOOR AJAR INDICATOR
LEFT REAR DOOR AJAR SWITCH
LOW OIL PRESSURE INDICATOR
LUGGAGE COMPARTMENT LID AJAR INDICATOR
LUGGAGE COMPARTMENT LIGHT SWITCH
MOUNTED TO FACIA)
NCA WIRE
PASSENGER'S DOOR AJAR SWITCH
PICTOGRAM
RED WIRE
RED/ WHT WIRE
RED/WHT WIRE
RIGHT FRONT DOOR INDICATOR
RIGHT REAR DOOR AJAR INDICATOR
RIGHT REAR DOOR AJAR SWITCH
TAILLAMPS FILAMENT MONITOR (RIGHT REAR OF LUGGAGE COMPARTMENT)
TAILLIGHT OUTAGE INDICATOR
WHT WIRE
YEL WIRE
Go to component -> Instrument cluster & pictogram circuit (2 of 2) -> RIGHT FRONT DOOR INDICATOR
