Saab 9000 I facelift (1991-1998) cassette for cd player/ equalizer Wiring diagram
This page shows the only wiring diagram for the component.cassette for cd player/ equalizer, which is found in the car Saab 9000 I facelift (1991-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cassette for cd player/ equalizer (1 of 1)
13 COND CABLE
ANTENNA
AUDIO SYSTEM AMPLIFIER
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
CASSETTE FOR CD PLAYER/ EQUALIZER
CD CHANGER
ELECTRICAL DISTRIBUTION BOX (BEHIND GLOVE BOX)
FUSE 19
FUSE 27
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT IN ACCY, RUN, OR START
LEFT FRONT SPEAKER
LEFT REAR SPEAKER
NCA WIRE
POWER ANTENNA SYSTEM
RADIO
RED WIRE
RED/WHT WIRE
RIGHT FRONT SPEAKER
RIGHT REAR SPEAKER
W/ PRESTIGE AUDIO SYSTEM ONLY
WHT WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Radio circuits -> CASSETTE FOR CD PLAYER/ EQUALIZER
