Saab 900 II (1993-1998) rear window heat element Wiring diagram
This page shows the only wiring diagram for the component.rear window heat element, which is found in the car Saab 900 II (1993-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear window heat element (1 of 1)
AUTOMATIC CLIMATE CONTROL MODULE (ON CENTER CONSOLE)
BLK WIRE
BRN WIRE
BRN/GRY WIRE
DASH- BOARD MAIN FUSE BOARD (BEHIND LEFT KICK PANEL)
DRIVER'S ELECTRICALLY ADJUSTABLE DOOR MIRROR
FUSE 1
FUSE 21
GRN/RED WIRE
GRY/BLK WIRE
HEATING ELEMENT
HOT AT ALL TIMES
HOT IN
IGNITION SWITCH
LOCK
PASSENGER'S ELECTRICALLY ADJUSTABLE DOOR MIRROR
REAR HEATED WINDOW SWITCH
REAR WINDOW HEAT ELEMENT
RED WIRE
RUN WIRE
W/ AUTOMATIC CLIMATE CONTROL
W/ AUTOMATIC CLIMATE CONTROL W/O AUTOMATIC CLIMATE CONTROL
W/O AUTOMATIC CLIMATE CONTROL
Go to component -> Defogger circuit -> REAR WINDOW HEAT ELEMENT
