Saab 900 II (1993-1998) main beam indicator Wiring diagram

1 2 COOLANT TEMPERATURE SENSOR (LEFT SIDE OF ENG) 1 3 RADIO AND CASSETTE PLAYER 2 1 OUTSIDE AIR TEMPERATURE SENSOR (UNDER FRONT CENTER BUMPER) 9 1 DATA LINK CONNECTOR (NEXT TO STEERING COLUMN) ABS CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) 21 23 ABS WARNING INDICATOR AIRBAG WARNING INDICATOR ANTI-THEFT SYSTEM BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/WHT WIRE BRAKE FLUID LEVEL SWITCH (IN BRAKE FLUID RESERVOIR) BRAKE FLUID WARNING INDICATOR BRN WIRE BRN/ORG WIRE BRN/WHT WIRE CHARGE INDICATOR CHECK GEAR BOX INDICATOR COOLANT TEMPERATURE GAUGE CRUISE CONTROL INDICATOR CRUISE CONTROL SYSTEM DASHBOARD MAIN FUSE BOARD (BEHIND LEFT KICK PANEL) DEFECTIVE LAMP INDICATOR DOOR OPEN INDICATOR ENGINE OIL PRESSURE SENSOR (ON OIL STUMP) EXH WARNING INDICATOR EXH WARNING RELAY (IN DASHBOARD MAIN RELAY BOARD, LEFT SIDE OF STEERING COLUMN) EXTERIOR LIGHTS SYSTEM (DIRECTION INDICATOR LAMPS) FUEL GAUGE FUEL LEVEL SENSOR (IN FUEL TANK) FUSE 17 FUSE 30 FUSE 34 GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE GRY/GRN WIRE GRY/WHT WIRE HANDBRAKE SWITCH (UNDER CENTER CONSOLE, ADJACENT TO HANDBRAKE) HEAD- LIGHTS SYSTEM HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM (REAR FOG LIGHT SWITCH) HOT AT ALL TIMES HOT WITH LIGHTS ON HOT IN START OR RUN ILLUMINATION INTERIOR LIGHTS SYSTEM (RHEOSTAT) LEFT FRONT DOOR SWITCH LEFT REAR DOOR SWITCH LEFT TURN INDICATOR LIGHT ON INDICATOR MAIN BEAM INDICATOR MAIN INSTRUMENT DISPLAY PANEL (STANDARD) MALFUNCTION INDICATOR LAMP (CHECK ENGINE) NCA WIRE OIL PRESSURE INDICATOR ORG/WHT WIRE PARK BRAKE INDICATOR REAR FOG LIGHTS INDICATOR RED WIRE RED/BLK WIRE RED/WHT WIRE RESERVE INDICATOR LIGHT RIGHT FRONT DOOR SWITCH RIGHT REAR DOOR SWITCH RIGHT TURN INDICATOR SAAB INFORMATION DISPLAY (SID) (CENTER CONSOLE) SPEEDOMETER SPORT INDICATOR STARTING/CHARGING SYSTEM (CHARGING CIRCUIT) SUPPLEMENTAL RESTRAINTS SYSTEM CONTROL MODULE TACHOMETER TRANS- MISSIONS SYSTEM VIO/WHT WIRE WASHER FLUID INDICATOR WATER FLUID LEVEL SWITCH WINTER INDICATOR YEL WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/WHT WIRE
