Saab 900 II (1993-1998) leg room adjust position sensor Wiring diagram
This page shows the only wiring diagram for the component.leg room adjust position sensor, which is found in the car Saab 900 II (1993-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram leg room adjust position sensor (1 of 1)
BACKREST RATE ADJUST MOTOR
BACKREST RATE ADJUST POSITION SENSOR
BACKWARD
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DASHBOARD MAIN FUSE BOARD (BEHIND LEFT KICK PANEL)
DOWN
DRIVER'S SIDE DOOR SWITCH
ELECTRICALLY ADJUSTABLE DRIVER'S SEAT RELAY (UNDER DRIVER'S SEAT)
ELECTRICALLY ADJUSTABLE DRIVER'S SEAT SWITCH
ELECTRICALLY ADJUSTABLE DRIVER'S SEAT WITH MEMORY SWITCH
FORWARD/
FRONT HEIGHT ADJUST MOTOR
FRONT HEIGHT ADJUST POSITION SENSOR
FUSE 16
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
INTEGRATED CENTRAL ELECTRONICS CONTROL MODULE
LEFT REAR DOOR SWITCH
LEG ROOM ADJUST MOTOR
LEG ROOM ADJUST POSITION SENSOR
NCA WIRE
PASSENGER'S SIDE DOOR SWITCH
REAR HEIGHT ADJUST MOTOR
REAR HEIGHT ADJUST POSITION SENSOR
RIGHT REAR DOOR SWITCH
WHT/BLK WIRE
YEL WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Driver's memory seat circuit -> LEG ROOM ADJUST POSITION SENSOR
