Saab 900 II (1993-1998) glass breakage sensor Wiring diagrams

ANTI- THEFT ALARM BONNET SWITCH ANTI- THEFT ALARM LED ANTI- THEFT ALARM SIREN BLK (OR BRN) WIRE BLK (OR WHT) WIRE BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLU (OR GRN/BLU) WIRE BLU WIRE BLU/GRN (OR GRY/GRN) WIRE BLU/GRN WIRE BLU/YEL WIRE BRN WIRE BRN/BLK (OR YEL/GRY) WIRE BRN/GRY WIRE BRN/RED WIRE CABRIO CENTRAL LOCKING SYSTEM CONTROL MODULE (BELOW RIGHT KICK PANEL) CENTRAL LOCKING TAILGATE MOTOR COMPUTER DATA LINES SYSTEM DASHBOARD MAIN FUSE BOARD (BEHIND LEFT KICK PANEL) DATA LINK CONNECTOR (UNDER DASH, NEXT TO STEERING COLUMN) DRIVER'S SIDE DOOR SWITCH EX CABRIO EXTERIOR LIGHTS SYSTEM (LEFT TURN INDICATORS) EXTERIOR LIGHTS SYSTEM (RIGHT TURN INDICATORS) FUSE 17 FUSE 23 FUSE 25 GLASS BREAKAGE SENSOR GRN (OR BLU) WIRE GRN/BLK WIRE GRN/BLU WIRE GRY WIRE GRY/BLK WIRE GRY/GRN WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT IN RUN OR START IGNITION SWITCH LUGGAGE COMPARTMENT LAMP LUGGAGE COMPARTMENT LIGHTING SWITCH NCA WIRE ORG) (OR BLK/ WIRE PASS- ENGER'S DOOR MICROSWITCH RED WIRE RED/BRN WIRE RED/WHT WIRE REMOTE CONTROL ANTI-THEFT ALARM AERIAL TAILGATE SWITCH TSAS CONTROL MODULE (CABRIO ONLY) (IN LUGGAGE COMPT) VIO/WHT WIRE WHT/BLK WIRE YEL WIRE YEL/GRY WIRE YEL/RED WIRE

60 56 58 56 63 1 (SE TURBO) (SE) (S) ANTI- THEFT ALARM BONNET SWITCH ANTI- THEFT ALARM LED ANTI- THEFT ALARM SIREN ANTI-THEFT ALARM CONTROL MODULE (UNDER LEFT FRONT SEAT) BLK (OR WHT) WIRE BLK WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU (OR BLK) WIRE BLU WIRE BLU/YEL WIRE BRN/GRY WIRE CABRIO CENTRAL LOCKING SYSTEM CONTROL MODULE (BELOW RIGHT KICK PANEL) COMPUTER DATA LINES SYSTEM DASHBOARD MAIN FUSE BOARD (BEHIND LEFT KICK PANEL) DATA LINK CONNECTOR (UNDER DASH, NEXT TO STEERING COLUMN) DRIVER'S SIDE DOOR SWITCH EX CABRIO EXTERIOR LIGHTS SYSTEM (LEFT TURN INDICATORS) EXTERIOR LIGHTS SYSTEM (RIGHT TURN INDICATORS) FUEL PUMP RELAY (IN DASH- BOARD MAIN RELAY BOARD, LEFT SIDE OF STEERING COLUMN) FUSE 17 FUSE 23 FUSE 25 FUSE 36 GLASS BREAKAGE SENSOR GRN WIRE GRN/BLU WIRE GRN/RED WIRE GRY/GRN WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT IN HOT IN RUN OR START LUGGAGE COMPARTMENT LAMP LUGGAGE COMPARTMENT LIGHTING SWITCH NCA WIRE ORG) (OR BLK/ WIRE PASS- ENGER'S DOOR MICROSWITCH RED WIRE REMOTE CONTROL ANTI-THEFT ALARM AERIAL RUN WIRE STARTING/CHARGING SYSTEM (STARTING CIRCUIT) TAILGATE SWITCH VIO/WHT WIRE WHT WIRE WHT/BLK WIRE YEL WIRE YEL/GRY WIRE YEL/RED WIRE
