Saab 900 II (1993-1998) front ashtray and cigarette lighter lamp Wiring diagram
This page shows the only wiring diagram for the component.front ashtray and cigarette lighter lamp, which is found in the car Saab 900 II (1993-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front ashtray and cigarette lighter lamp (1 of 1)
AUTOMATIC CLIMATE CONTROL CONTROL MODULE
BLK WIRE
BRN/RED WIRE
BRN/WHT WIRE
DASHBOARD MAIN FUSE BOARD (BEHIND LEFT KICK PANEL)
DASHBOARD MAIN FUSE BOARD (BEHIND LEFT KICK PANEL) FUSE 29
ELEC- TRIC- ALLY HEATED REAR SEAT SWITCH
ELECTRIC WINDOW LIFTS/ ELECTRIC SUNROOF SWITCH
ENGINE COMPARTMENT MAIN FUSE BOX (LEFT SIDE OF BATTERY)
EXTRA FOG LIGHT SWITCH
FRONT ASHTRAY AND CIGARETTE LIGHTER LAMP
FUSE 15
FUSE 30
GLOVE BOX LIGHT LAMP
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
GRY/RED WIRE
GRY/WHT WIRE
HAZARD FLASHER SWITCH
HEAD
HEADLIGHT SYSTEM
HEATING AND VENTILATION CONTROL PANEL
HEATING CONTROL LIGHTING LAMP
HOT AT ALL TIMES
IGNITION SWITCH HOT IN
LEFT SEAT HEATING PAD SWITCH
LIGHT SWITCH
LOCK
MAIN INSTRUMENT DISPLAY PANEL (STANDARD)
MAXI FUSE 2
MOBILE TELEPHONE CONNECTOR
OFF PARK
OFF PARK HEAD
ORG/ WIRE
RADIO CONNECTOR SWITCH B
REAR FOG LIGHT SWITCH
RED WIRE
RHEOSTAT
RIGHT SEAT HEATING PAD SWITCH
RUN WIRE
SAAB INFORMATION DISPLAY (SID)
SELECTOR LEVER LAMP
TCS OFF SWITCH (1996-97 ONLY)
VENTILATION FAN CONTROL
VIO/WHT WIRE
W/ AUTOMATIC CLIMATE CONTROL
W/O AUTOMATIC CLIMATE CONTROL
WHT WIRE
WINTER SWITCH
YEL/BLK WIRE
Go to component -> Instrument illumination circuit -> FRONT ASHTRAY AND CIGARETTE LIGHTER LAMP
