Saab 900 II (1993-1998) cruise control selector switch Wiring diagram
This page shows the only wiring diagram for the component.cruise control selector switch, which is found in the car Saab 900 II (1993-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cruise control selector switch (1 of 1)
ABS CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/GRN (OR GRN/WHT OR VIO) WIRE
BLK/GRN WIRE
BLU WIRE
BLU/GRN (OR VIO) WIRE
BLU/GRN WIRE
BRAKE LIGHT SWITCH (ON BRAKE PEDAL)
BRN/GRY WIRE
BRN/WHT WIRE
CRUISE CONTROL BRAKE SWITCH (ON BRAKE PEDAL)
CRUISE CONTROL CLUTCH SWITCH (ON CLUTCH PEDAL)
CRUISE CONTROL INDICATOR
CRUISE CONTROL MODULE (UNDER LEFT SIDE OF DASH)
CRUISE CONTROL SELECTOR SWITCH
DASHBOARD MAIN FUSE BOARD (BEHIND LEFT KICK PANEL)
FUSE 12
FUSE 9
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
HOT IN RUN FUSE 22
HOT IN START, RUN OR ACCY
MAIN INSTRUMENT DISPLAY PANEL
NCA WIRE
SAAB SENSONIC CONTROL MODULE (BEHIND GLOVE BOX)
TCM CONTROL MODULE (BEHIND GLOVE BOX)
TCS CONTROL MODULE
TRANS- MISSION RANGE SWITCH 2
VIO WIRE
W/ A/T
W/ M/T
W/ SENSONIC AUTO CLUTCH
W/O TCS
YEL/GRN WIRE
YEL/GRY WIRE
YEL/WHT (OR BRN/GRY) WIRE
YEL/WHT WIRE
