Saab 900 II (1993-1998) console) tsas control module (in luggage Wiring diagram
This page shows the only wiring diagram for the component.console) tsas control module (in luggage, which is found in the car Saab 900 II (1993-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram console) tsas control module (in luggage (1 of 1)
ANTI-THEFT ALARM CONTROL MODULE (UNDER LEFT
ANTI-THEFT W/ VSS
ANTI-THEFT W/O VSS ANTI-THEFT W/ VSS
AUTOMATIC CLIMATE CONTROL MODULE
BLK WIRE
BLK/WHT (OR BLK) WIRE
BLU/ORG WIRE
BOARD, ADJACENT TO THE STEERING COLUMN) ABS
BOX) AIRBAG CONTROL MODULE (UNDER CENTER
BRN/BLK WIRE
BRN/ORG WIRE
COMPT) ICE CONTROL MODULE (UNDER THE DASH-
CONSOLE) TSAS CONTROL MODULE (IN LUGGAGE
CONTROL MODULE (LEFT SIDE OF
DASHBOARD MAIN FUSE BOARD (BEHIND LEFT KICK PANEL)
DATA LINK CONNECTOR (UNDER THE DASH, NEXT TO STEERING COLUMN)
ELECTRICALLY ADJUSTABLE DRIVER'S SEAT W/ MEMORY CONTROL MODULE
ENGINE COMPT)
FRONT SEAT)
FRONT SEAT) SAAB SENSONIC CONTROL MODULE (BEHIND GLOVE
FUEL PUMP RELAY (IN DASHBOARD MAIN RELAY BOARD, LEFT SIDE OF STEERING COLUMN)
FUSE 13
GRY/BLK WIRE
HOT AT ALL TIMES
J/C
MAIN INSTRUMENT DISPLAY PANEL (UP LEVEL)
MOTRONIC/ TRIONIC CONTROL MODULE (RIGHT KICK PANEL)
RADIO CONNECTIONS
RED/BLK WIRE
SAAB INFORMATION DISPLAY (SID)
TCS CONTROL MODULE (UNDER RIGHT
W/ ANTI- THEFT
W/O ANTI- THEFT
WHT WIRE
WHT/BLK (OR BLK) WIRE
WHT/BLK WIRE
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> Computer data lines -> CONSOLE) TSAS CONTROL MODULE (IN LUGGAGE
