Saab 900 II (1993-1998) 2-speed radiator fan high speed relay Wiring diagram
This page shows the only wiring diagram for the component.2-speed radiator fan high speed relay, which is found in the car Saab 900 II (1993-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 2-speed radiator fan high speed relay (1 of 1)
1-SPEED FAN
2-SPEED FAN
2-SPEED RADIATOR
2-SPEED RADIATOR FAN HIGH SPEED RELAY
A/C HIGH PRESSURE SWITCH
BLK WIRE
BRN WIRE
BRN/GRY WIRE
BRN/RED WIRE
COOLANT TEMPERATURE SENSOR
ENGINE COMPARTMENT FUSE/RELAY BOARD (FAR LEFT REAR CORNER OF ENGINE COMPARTMENT)
FAN RESISTOR (ON RADIATOR FAN COVER)
FUSE 3
FUSE 4
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LOW SPEED RELAY
NCA WIRE
RADIATOR FAN MOTOR (FRONT OF ENGINE COMPARTMENT)
RED WIRE
VIO WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/GRY WIRE
Go to component -> Cooling fan circuit -> 2-SPEED RADIATOR FAN HIGH SPEED RELAY
