Rear wiper/washer circuit for Saab 9-7X I (2005-2009)
Rear wiper/washer circuit
BATTERY
BLK WIRE
BODY CONTROL MODULE (BCM) (BENEATH LEFT REAR SEAT, ON REAR FUSE BLOCK)
CLASS 2 SER DATA
CONT
DK BLU/WHT WIRE
DK GRN WIRE
DLY
GRY WIRE
HOT AT ALL TIMES
LIFTGATE MODULE (LGM) (IN CENTER OF LIFTGATE)
LOGIC
LT BLU WIRE
LT GRN WIRE
OFF
ORG/ WIRE
REAR FUSE BLOCK (BELOW LEFT REAR SEAT)
REAR WASHER RELAY
REAR WINDOW MOTOR SPEED SIGNAL
REAR WINDOW MTR SPEED SIGNAL
REAR WINDOW WASHER FLUID PUMP (ON WASHER FLUID RESERVOIR)
REAR WINDOW WIPER MOTOR (INSIDE TAILGATE)
REAR WINDOW WIPER/WASHER SWITCH
REAR WIPER SW SIG
REAR WPR CIRCUIT BREAKER 9
REAR/WPR RELAY 38
SOUND SYSTEMS
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPARTMENT)
W/ STEERING WHEEL CONTROLS
WASH
WHT WIRE
WPR FUSE 7
