Transfer case circuit for Saab 9-7X I (2005-2009)

Transfer case circuit

9-7X Saab I (2005-2009): Transfer case circuit

Get access

850 1640 1552 1553 GROUND BATTERY MOTOR CTRL A MOTOR CTRL B ATC FUSE 8 BLK WIRE BLK/WHT WIRE BRN/WHT WIRE CLASS 2 DATA COMPUTER DATA LINES SYSTEM DK GRN WIRE DK GRN/WHT WIRE ENCODER ENCODER SIG GROUND GRY WIRE HOT AT ALL TIMES HOT IN RUN OR START I/P HARNESS PASS-THROUGH) IGN E FUSE 22 IND INSTRUMENT PANEL CLUSTER (IPC) LOGIC LOW REF LT BLU WIRE NCA WIRE NEAR HEADLAMP SWITCH CONNECTOR) SPLICE PACK ORG/ WIRE PNK WIRE PPL PPL DATA LINK CONNECTOR (ON BOTTOM LEFT SIDE OF DASH) PPL FRONT SIG LO FRONT SIG HI PROPSHAFT SPEED SENSOR (LEFT FRONT) (ON LEFT FRONT OF TRANSFER CASE) REAR SIG HI REAR SIG LO RED WIRE SERVICE TRANSFER CASE SHIFT CONTROL MODULE (BEHIND LOWER LEFT SIDE OF DASH) UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT) YEL WIRE
