Electronic suspension circuit for Saab 9-7X I (2005-2009)
Electronic suspension circuit
AIR SUSPENSION COMPRESSOR ASSEMBLY (BEHIND RIGHT REAR WHEELWELL, ON FRAME RAIL)
AIR SUSPENSION INFLATOR SWITCH (ON RIGHT SIDE OF CARGO AREA, ON TRIM PANEL)
BLK WIRE
BRN WIRE
DK GRN/WHT WIRE
ECAS FUSE 1
FUSE 49
HOT AT ALL TIMES
HOT IN RUN
INSTRUMENT PANEL CLUSTER
LEFT REAR AIR SUSPENSION SENSOR (ON FRAME RAIL, NEAR LEFT REAR SUSPENSION ARM)
ORG/ WIRE
POWERTRAIN CONTROL MODULE (4.2L)
PPL
RADIO (PREMIUM)
REAR FUSE BLOCK (BELOW LEFT REAR SEAT)
RED WIRE
RIGHT REAR AIR SUSPENSION SENSOR (ON FRAME RAIL, NEAR RIGHT REAR SUSPENSION ARM)
SW SIG GROUND IND CTRL
TAN WIRE
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT)
VSS
