Saab 9-7X I (2005-2009) w/s wash relay 42 Wiring diagram
This page shows the only wiring diagram for the component.w/s wash relay 42, which is found in the car Saab 9-7X I (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/s wash relay 42 (1 of 1)
BLK WIRE
BODY CONTROL MODULE (BCM) (BENEATH LEFT REAR SEAT, ON REAR FUSE BLOCK)
HDLP WASH RLY CTRL
HEADLAMP WASHER FLUID PUMP (RIGHT FRONT OF ENGINE COMPARTMENT)
HEADLAMP WPR RELAY 37
HOT AT ALL TIMES
ORG/ WIRE
PPL
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPARTMENT)
W/S WASH RELAY 42
WASHER RLY CTRL
WHT WIRE
WPR FUSE 7
WSW FUSE 9
Go to component -> Headlamp washer circuit -> W/S WASH RELAY 42
