Saab 9-7X I (2005-2009) to ign 1 relay 60 relay 64 Wiring diagram
This page shows the only wiring diagram for the component.to ign 1 relay 60 relay 64, which is found in the car Saab 9-7X I (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram to ign 1 relay 60 relay 64 (1 of 1)
5.3L
A/C RELAY 44 FOG LAMP RELAY
ACCY RELAY 29
AIR SUSPENSION COMPRESSOR ASSEMBLY
BLK WIRE
BLOWER FUSE 36 FUSE 35
BLOWER MOTOR CONTROL MODULE
BODY CONTROL MODULE
BODY CONTROL MODULE (BCM)
BRAKE FUSE 52
BRN WIRE
DATA LINK CONNECTOR (DLC)
EAP FUSE 15 FUSE 59 (4.2L) (5.3L)
EAP RELAY 49 (IF EQUIPPED)
ECAS FUSE 1
ELECTRONIC ADJUSTABLE PEDALS (EAP) RELAY (IF EQUIPPED)
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
FLAT WIRE
FOG LAMP FUSE 11 A/C FUSE 30
FROM ATC FUSE 8 (DIAGRAM 1 OF 5)
FROM HVAC I FUSE 40 (DIAGRAM 1 OF 5)
FROM IGNITION SWITCH (DIAGRAM 1 OF 5)
FROM TBC 1 FUSE 31 (DIAGRAM 3 OF 5)
FROM UNDERHOOD FUSE BLOCK (DIAGRAM 3 OF 5)
FRT WPR FUSE 33
HAZRD FUSE 52 (4.2L) (5.3L)
HEADLAMP WPR RELAY 37 (W/ WASHER HEADLAMP)
HORN FUSE 21
HORN RELAY 40
IGN A FUSE 34
INSTRUMENT PANEL CLUSTER (IPC)
IPC/DIC FUSE 24
LEFT TRAILER STOP/TURN RELAY
LTR FUSE 13 (4.2L) (5.3L)
ORG/ WIRE
PNK WIRE
POWERTRAIN RELAY 60
REAR FUSE BLOCK (BELOW LEFT REAR SEAT)
REAR/WPR RELAY 38
RED WIRE
REGULATED VOLTAGE CONTROL MODULE TURN SIGNAL/ HAZARD FLASHER MODULE
RIGHT TRAILER STOP/TURN RELAY
RVC FUSE 59 FUSE 66
STARTER RELAY 47
STOP LAMP FUSE 12
STOP LAMP SWITCH
TBC ACC FUSE 31
TCM FUSE 36
TO ECM FUSE 29 (DIAGRAM 3 OF 5)
TO IGN 1 RELAY 60 RELAY 64
TO IGN 3 RELAY 34 (DIAGRAM 1 OF 5)
TRANSMISSION CONTROL MODULE (TCM)
TRLR STOP/TURN FUSE 14 FUSE 17
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT)
W/ HID W/O HID
WINDSHIELD WIPER MOTOR
WPR FUSE 7
WSW FUSE 9
WSW RELAY 42
YEL WIRE
Go to component -> Power distribution circuit (2 of 5) -> TO IGN 1 RELAY 60 RELAY 64
