Saab 9-7X I (2005-2009) sunroof switch close signal sunroof switch low reference Wiring diagram
This page shows the only wiring diagram for the component.sunroof switch close signal sunroof switch low reference, which is found in the car Saab 9-7X I (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sunroof switch close signal sunroof switch low reference (1 of 1)
BATTERY POSITIVE VOLTAGE
BLK WIRE
BLK/PPL WIRE
BODY CONTROL MODULE (BCM) (BENEATH LEFT REAR SEAT, ON REAR FUSE BLOCK)
BRN WIRE
BRN/WHT WIRE
CLOSE OPEN
DK BLU WIRE
GROUND
HOT AT ALL TIMES
HOT WITH RAP ENERGIZED
LT BLU WIRE
NCA WIRE
ORG/ WIRE
PPL
RAP FUSE SUPPLY VOLTAGE
REAR FUSE BLOCK (BELOW LEFT REAR SEAT)
SUNROOF FUSE 28
SUNROOF MOTOR
SUNROOF SWITCH
SUNROOF SWITCH CLOSE SIGNAL SUNROOF SWITCH LOW REFERENCE
SUNROOF SWITCH OPEN SIGNAL
WHT WIRE
YEL/RED WIRE
Go to component -> Power top/sunroof circuit -> SUNROOF SWITCH CLOSE SIGNAL SUNROOF SWITCH LOW REFERENCE
