Saab 9-7X I (2005-2009) rollover sensor Wiring diagram
This page shows the only wiring diagram for the component.rollover sensor, which is found in the car Saab 9-7X I (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rollover sensor (1 of 1)
5.3L
A/C LOW PRESSURE SWITCH
AMPLIFIER GROUND SHIELD ONSTAR GROUND SHIELD
BARE BARE
BATTERY
BLK WIRE
BLK/WHT WIRE
COOLING FAN
DATA LINK CONNECTOR
DIGITAL RADIO RECEIVER (IF EQUIPPED)
DK GRN WIRE
FRONT FOG LAMP SWITCH HEADLAMP DIMMER SWITCH
GRN WIRE
HEADLAMP SWITCH
HEADLAMP WASHER FLUID PUMP
HORN ASSEMBLY
HVAC CONTROL MODULE
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3 IGNITION COIL 1 IGNITION COIL 5
IGNITION COIL 4
IGNITION COIL 5 IGNITION COIL 3
IGNITION COIL 6
IGNITION COIL 7 IGNITION COIL 2 IGNITION COIL 4
IGNITION COIL 8
IGNITION KEY ALARM SWITCH THEFT DETERRENT CONTROL MODULE
IGNITION SWITCH
INFLATABLE RESTRAINT FRONT PASSENGER PRESENCE SYSTEM (PPS) MODULE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM)
INSTRUMENT PANEL CLUSTER (IPC)
NCA WIRE
RADIO
RADIO GROUND SHIELD 1
RADIO GROUND SHIELD 2
REAR WINDOW WASHER FLUID PUMP
RIGHT FRONT FOG LAMP
RIGHT FRONT PARK/TURN SIGNAL LAMP
RIGHT HEADLAMP
RIGHT HEADLAMP LOW BEAM RIGHT HEADLAMP HIGH BEAM
ROLLOVER SENSOR
STEERING WHEEL SPEED/ POSITION SENSOR
TAN WIRE
TRACTION CONTROL SWITCH
TRANSFER CASE SHIFT CONTROL MODULE
TURN SIGNAL/ MULTIFUNCTION SWITCH
UNDERHOOD FUSE BLOCK
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT)
W/ HID W/O HID
W/ HIGH PRESSURE HEADLAMP WASHER
W/ PREMIUM AUDIO BRANDED W/ AMPLIFIER SPEAKER SYSTEM BARE BARE
WHT WIRE
WINDSHIELD WASHER FLUID LEVEL SWITCH
WINDSHIELD WASHER FLUID PUMP
Go to component -> Ground distribution circuit (1 of 5) -> ROLLOVER SENSOR
