Saab 9-7X I (2005-2009) rl turn fuse 39 veh stop fuse 35 Wiring diagram
This page shows the only wiring diagram for the component.rl turn fuse 39 veh stop fuse 35, which is found in the car Saab 9-7X I (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rl turn fuse 39 veh stop fuse 35 (1 of 1)
BLK WIRE
BODY CONTROL MODULE (BCM) (BENEATH LEFT REAR SEAT, ON REAR FUSE BLOCK)
BRN WIRE
BRN/WHT WIRE
CENTER HIGH MOUNTED STOP LAMP (CHMSL)
DK BLU WIRE
DK GRN WIRE
DK LT
DRIVER DOOR MODULE (DDM) (BELOW DRIVER'S DOOR SWITCH PANEL)
DRIVER OUTSIDE REARVIEW MIRROR
FL TRN FUSE 51
FR TRN FUSE 41
FROM FRT PRK FUSE 38 (DIAGRAM 1 OF 2)
FRONT PASSENGER DOOR MODULE (FPDM) (BELOW FRONT PASSENGER DOOR SWITCH PANEL)
GRD
GRN WIRE
HAZARD FUSE 52
HOT AT ALL TIMES
HOT IN RUN OR START
IGN E FUSE 22
INSTRUMENT CLUSTER SYSTEM
LEFT LICENSE LAMP
LEFT REAR MARKER LAMP
LEFT REAR STOP/PARK LAMP
LEFT REAR TURN SIGNAL LAMP
LEFT RIGHT
LR PARK FUSE 14
LT BLU WIRE
LT GRN WIRE
LT TRN SIG VOLTAGE
MIRROR LT TURN SIG
MIRROR RT TURN SIG
MJR
MNR
MNR (NOT USED)
NCA WIRE
ORG/ WIRE
PASSENGER OUTSIDE REARVIEW MIRROR
PNK WIRE
PPL
REAR FUSE BLOCK (BELOW LEFT REAR SEAT)
RIGHT LICENSE LAMP
RIGHT REAR MARKER LAMP
RIGHT REAR STOP/PARK LAMP
RIGHT REAR TURN SIGNAL LAMP
RL TURN FUSE 39 VEH STOP FUSE 35
RR PARK FUSE 17
RR TURN FUSE 44
RT TRN SIG VOLTAGE
STOP LAMP FUSE 12
STOP LAMP SWITCH (ON BRAKE PEDAL ASSEMBLY)
TAN WIRE
TRLR LT TRN FUSE 51
TRLR PRK FUSE 43
TRLR RT TRN FUSE 50
TURN SIGNAL/ MULTI-FUNCTION SWITCH
TURN SIGNAL/HAZARD FLASHER MODULE (BEHIND LOWER LEFT SIDE OF DASH)
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT)
VEH CHMSL FUSE 16
W/O HID W/ HID 1 2
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> RL TURN FUSE 39 VEH STOP FUSE 35
