Saab 9-7X I (2005-2009) (on left hand frame rail near Wiring diagram
This page shows the only wiring diagram for the component.(on left hand frame rail near, which is found in the car Saab 9-7X I (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (on left hand frame rail near (1 of 1)
2 3 PNK WIRE
5 6 7 8 9 PNK PNK WIRE
AIR PUMP FUSE 56
AIR SOL FUSE 54
AIR SOL RELAY 55
BLK WIRE
BLK/WHT PNK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
CAMSHAFT ACTUATOR SOLENOID ASSEMBLY (ON RIGHT FRONT OF CYLINDER HEAD)
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN/WHT WIRE
ELECTRONIC BRAKE CONTROL MODULE) SECONDARY AIR INJECTION (AIR) PUMP
ETC FUSE 23 FUSE 29
EVAPORATIVE EMISSION (EVAP) CANISTER PURGE SOLENOID (LOWER LEFT SIDE OF ENGINE)
EVAPORATIVE EMISSION (EVAP) CANISTER VENT SOLENOID (AT REAR OF FUEL TANK)
FUEL PUMP RELAY 41
FUEL PUMP, SENDER ASSEMBLY (INSIDE FUEL TANK)
GRY WIRE
HEATED OXYGEN SENSOR 2 (DOWNSTREAM OF CATALYTIC CONVERTER, ON EXHAUST PIPE)
HOT AT ALL TIMES
HOT IN RUN OR START
MAF
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PCM B FUSE 10
PNK WIRE
PNK/BLK WIRE
PPL
PPL PNK PNK 1 2 3 4 5 WIRE
PPL/WHT WIRE
PWRTRN RELAY 61
RED WIRE
SECONDARY AIR INJECTION (AIR) PUMP RELAY (LEFT FRONT OF CHASSIS)
SECONDARY AIR INJECTION (AIR) SOLENOID (UPPER RIGHT SIDE OF ENGINE)
TAN WIRE
TAN/WHT WIRE
TCM CNSTR FUSE 26
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 4.2l (2 of 5) -> (ON LEFT HAND FRAME RAIL NEAR
