Saab 9-7X I (2005-2009) left headlamp high beam Wiring diagram
This page shows the only wiring diagram for the component.left headlamp high beam, which is found in the car Saab 9-7X I (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left headlamp high beam (1 of 1)
4.2L
5.3L
5.3L (NOT USED)
5.3L 4.2L
A/C COMPRESSOR CLUTCH ASSEMBLY SECONDARY AIR INJECTION (AIR) SOLENOID
BARE
BLK WIRE
BRAKE FLUID LEVEL SWITCH
DK GRN WIRE
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
FAN RELAY 45
FRONT PASSENGER DOOR MODULE (FPDM)
FUEL PUMP RELAY 41
INTAKE AIR TEMPERATURE (IAT)/MASS AIR FLOW (MAF) SENSOR
LEFT FRONT FOG LAMP
LEFT FRONT PARK/TURN SIGNAL LAMP
LEFT HEADLAMP
LEFT HEADLAMP HIGH BEAM
LEFT HEADLAMP LOW BEAM
ONSTAR MICROPHONE GROUND SHIELD 2
PARK/ NEUTRAL POSITION (PNP) SWITCH
PASSENGER SEAT ADJUSTER SWITCH PASSENGER LUMBAR ADJUSTER SWITCH
POWERTRAIN CONTROL MODULE (PCM)/ ENGINE CONTROL MODULE (ECM)
REGULATED VOLTAGE CONTROL MODULE
RIGHT REAR DOOR LATCH ASSEMBLY RIGHT REAR WINDOW SWITCH
TRANSMISSION CONTROL MODULE (TCM)
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT)
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM)
W/ HID W/O HID
WHT WIRE
Go to component -> Ground distribution circuit (4 of 5) -> LEFT HEADLAMP HIGH BEAM
