Saab 9-7X I (2005-2009) fog lamp relay 39 Wiring diagrams
This page contains all the electrical diagrams for the component. fog lamp relay 39, in which he is found in the car Saab 9-7X I (2005-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram fog lamp relay 39 (1 of 2)
AMBIENT LIGHT/ SUNLOAD SENSOR ASSEMBLY (ON TOP CENTER OF
AUTO
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (BENEATH LEFT REAR SEAT, ON
BRN/WHT WIRE
COILS FUSE 14 (5.3L)
DASH, NEAR BASE OF WINDSHIELD)
DIMMER, PASSING SWITCH
DK GRN WIRE
DK GRN/WHT WIRE
DRL DEFEAT AUTO
FLASH TO PASS
FOG LAMP FUSE 11
FOG LAMP RELAY 39
FRONT FOG LAMP SWITCH
GRY/BLK WIRE
HEAD
HEAD DRL DEFEAT
HEADLAMP SWITCH
HI-BEAM HEADLAMP RELAY 43
HOT AT ALL TIMES
LEFT FRONT FOG LAMP RIGHT FRONT FOG LAMP
LEFT HEAD- LAMP
LEFT HIGH BEAM HEADLAMP
LEFT LOW BEAM HEADLAMP
LOW BEAM HIGH BEAM
LOW BEAM RELAY 59 RELAY 63
LT GRN WIRE
LT HDLP FUSE 35 FUSE 36 (4.2L) (5.3L)
LT HIGH HDLP FUSE 5
MODULE (BEHIND LOWER LEFT SIDE OF DASH)
ORG/ WIRE
PARK
PARK HEAD DRL DEFEAT
PNK/WHT WIRE
PPL
REAR FUSE BLOCK
RH HDLP FUSE 58 FUSE 62
RIGHT HEAD- LAMP
RIGHT HIGH BEAM HEADLAMP
RIGHT LOW BEAM HEADLAMP
RLY CTRL RLY CTRL LOW REF SENS SIG
RT HI HDLP FUSE 2
TAN WIRE
TURN SIGNAL/ HAZARD FLASHER
TURN SIGNAL/ MULTIFUNCTION SWITCH
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Headlights circuit, with high intensity discharge -> FOG LAMP RELAY 39
Wiring diagram fog lamp relay 39 (2 of 2)
AMBIENT LIGHT/ SUNLOAD SENSOR ASSEMBLY (ON TOP CENTER OF
AUTO
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (BENEATH LEFT REAR SEAT, ON
BRN/WHT WIRE
DASH, NEAR BASE OF WINDSHIELD)
DIMMER, PASSING SWITCH
DK GRN WIRE
DK GRN/WHT WIRE
DRL DEFEAT AUTO
FLASH TO PASS
FOG LAMP FUSE 11
FOG LAMP RELAY 39
FRONT FOG LAMP SWITCH
GRY/BLK WIRE
HDM FUSE 53 FUSE 57
HEAD
HEAD DRL DEFEAT
HEADLAMP DRIVER MODULE RELAY 46
HEADLAMP SWITCH
HI-BEAM HEADLAMP RELAY 43
HOT AT ALL TIMES
IGN COILS FUSE 14 (5.3L)
LEFT FRONT FOG LAMP RIGHT FRONT FOG LAMP
LEFT HEAD- LAMP
LEFT HIGH BEAM HEADLAMP
LEFT LOW BEAM HEADLAMP
LOW BEAM HIGH BEAM
LT GRN WIRE
LT HIGH HDLP FUSE 5
LT LOW HDLP FUSE 6
ORG/ WIRE
PARK
PARK HEAD DRL DEFEAT
PNK WIRE
PNK/WHT WIRE
PPL
REAR FUSE BLOCK
RIGHT HEAD- LAMP
RIGHT HIGH BEAM HEADLAMP
RIGHT LOW BEAM HEADLAMP
RLY CTRL RLY CTRL LOW REF SENS SIG
RT HI HDLP FUSE 2
RT LOW HDLP FUSE 3
TAN WIRE
TURN SIGNAL/ MULTIFUNCTION SWITCH
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Headlights circuit, without high intensity discharge -> FOG LAMP RELAY 39
