Saab 9-7X I (2005-2009) courtesy lps pwr remote radio ctrl sig rear wiper sw sig Wiring diagram

4.2L 5.3L AIR CONDITIONING SYSTEM BLK WIRE BLK/WHT WIRE BLOCK (BELOW LEFT REAR SEAT) BODY CONTROL MODULE (BCM) (BENEATH LEFT REAR SEAT, ON REAR FUSE BLOCK) COURTESY LPS PWR REMOTE RADIO CTRL SIG REAR WIPER SW SIG DK BLU/WHT WIRE DK GRN WIRE DK GRN/WHT WIRE DOOR LOCKS SYSTEM POWER WINDOWS SYSTEM DRL DEF SW SIG HEADLP SW ON SIG HEADLP HIGH BEAM PWR INT LP DEFEAT SW SIG DRL SWITCH SIG FOG LAMP RELAY CTRL HORN RELAY CTRL FLAT WIRE FLAT WIRE ACCESSORY VOLTAGE FLAT WIRE FLAT WIRE FLAT WIRE FLAT WIRE BAT POSITIVE VOLTAGE COURTESY LAMP PWR FLAT WIRE FLAT WIRE FLAT WIRE GROUND BACK UP LAMP PWR BAT POSITIVE VOLTAGE FLAT WIRE LR DOOR AJAR SW SIG GRY WIRE GRY/BLK WIRE HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM HORNS SYSTEM HOT AT ALL TIMES HOT IN ACC OR RUN HOT IN ACC, RUN OR START HOT IN ON OR START HOT IN RUN IGN E FUSE 22 KEY IN IGN SW SIG FLASH-TO-PASS SW SIG PARK LP SW SIG LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE ORG/ WIRE ORG/BLK WIRE PARK BRAKE SWITCH (ON PARKING BRAKE ASSEMBLY) PCM I FUSE 28 PNK WIRE PNK/WHT WIRE POWER DISTRIBUTION SYSTEM POWER TOPS SYSTEM DOOR LOCKS SYSTEM EXTERIOR LIGHTS SYSTEM POWER WINDOWS SYSTEM PPL REAR FUSE REAR FUSE BLOCK (BELOW LEFT REAR SEAT) RIGHT SUNLOAD SEN SIG LEFT SUNLOAD SEN SIG SOUND SYSTEMS INTERIOR LIGHTS SYSTEM SOUND SYSTEMS WIPER/WASHER SYSTEM TBC 2 FUSE 7 TBC 3 FUSE 4 TBC 4 FUSE 53 TBC 5 FUSE 32 TBC ACCY FUSE 31 UNDERHOOD TBC I FUSE BLOCK FUSE 31 (ON LEFT SIDE OF FUSE 58 ENGINE COMPT) WARNING SYSTEM HEADLIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM WHT WIRE WINDSH WIPER SW SIG 2 COURTESY LPS SIG WINDSH WASH RLY CTRL FRONT FOG LPS SW SIG WIPER/WASHER SYSTEM WIPER/WASHER SYSTEM INTERIOR LIGHTS SYSTEM WIPER/WASHER SYSTEM HEADLIGHTS SYSTEM YEL WIRE
