Tire pressure monitoring circuit for Saab 9-5 II (2010-2012)
Tire pressure monitoring circuit
BATT POSITIVE VOLT
BATTERY POSITIVE VOL
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (LEFT END OF DASH)
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER (DIC) DISPLAY
FUSE 21
GRN WIRE
GRN/BLU WIRE
GRY WIRE
HI SPD GMLAN SRL DATA (-) HI SPD GMLAN SRL DATA (+)
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK (LEFT END OF DASH)
LIN BUS 2
LOGIC
LOW SPD GMLAN SERIAL DATA
LOW TIRE PRESSURE IND
RED WIRE
RED/GRY WIRE
TIRE PRESSURE INDICATOR MODULE (LEFT SIDE OF LUGGAGE COMPT)
WHT WIRE
