Head-up display circuit for Saab 9-5 II (2010-2012)
Head-up display circuit
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
COMPUTER DATA LINES SYSTEM
FUSE 5
GRN WIRE
GROUND
GRY/YEL WIRE
HEAD-UP DISPLAY
HEAD-UP DISPLAY SWITCH
HOT AT ALL TIMES
HUD OFF/ DIMMING SIG
HUD SW SIG
IMAGE DN
IMAGE UP
INSTRUMENT PANEL FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
LO SPD GMLAN SER DATA
LOW REFERENCE
RED WIRE
RED/GRN WIRE
YEL WIRE
YEL/WHT WIRE
