Saab 9-5 II (2010-2012) w/ passive remote keyless entry Wiring diagram
This page shows the only wiring diagram for the component.w/ passive remote keyless entry, which is found in the car Saab 9-5 II (2010-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ passive remote keyless entry (1 of 1)
BLK WIRE
BLK/WHT WIRE
BRAKE FLUID LEVEL SWITCH
BRN WIRE
DRIVER EXTERIOR DOOR HANDLE SWITCH
DRIVER INTERIOR DOOR HANDLE SWITCH
FORMED CONDUIT NEAR LEFT B-PILLAR, NEAR C-PILLAR)
LEFT REAR EXTERIOR DOOR HANDLE SWITCH
LEFT SIDE OBJECT SENSOR
MULTI-AXIS ACCELERATION SENSOR
NCA WIRE
OVERHEAD CONSOLE MULTI- FUNCTION SWITCH
PASSENGER AIR BAG HAZARD DISABLE LAMPS INDICATOR SWITCH
PASSENGER EXTERIOR DOOR HANDLE SWITCH
PASSENGER INTERIOR DOOR HANDLE SWITCH
RIGHT REAR EXTERIOR DOOR HANDLE SWITCH
RIGHT SIDE OBJECT SENSOR
SUSPENSION CONTROL MODULE
TIRE PRESSURE INDICATOR MODULE
TRAILER CONNECTOR
TRAILER IGNITION RELAY
TRAILER LIGHTING CONTROL MODULE
W/ LIGHT SENSITIVE MIRROR, LANE DEPARTURE WARNING, WINDSHIELD WIPER SYSTEM
W/ LIGHT SENSITIVE MIRROR, W/O LANE DEPARTURE WARNING, WINDSHIELD WIPER SYSTEM
W/ PASSIVE REMOTE KEYLESS ENTRY
Go to component -> Ground distribution circuit (7 of 8) -> W/ PASSIVE REMOTE KEYLESS ENTRY
