Saab 9-5 II (2010-2012) rear compartment lid release relay Wiring diagrams
This page contains all the electrical diagrams for the component. rear compartment lid release relay, in which he is found in the car Saab 9-5 II (2010-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rear compartment lid release relay (1 of 2)
BATT POS VOLT
BLK WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (LEFT END OF DASH)
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DOOR LCK ACTUATOR UNLK CONTROL
DOOR LOCKS SYSTEM
DR ACTR LCK CTRL 2
DRIVER INFORMATION CENTER DISPLAY
EXTERIOR REAR COMPARTMENT LID UNLATCH SWITCH
FDL RELAY CONTROL
FUEL DOOR RELEASE ACTUALOR RELAY
FUEL DOOR UNLATCH ACTUATOR (RIGHT SIDE OF LUGGAGE COMPARTMENT)
FUSE 14
FUSE 3
GRN WIRE
GRY WIRE
GRY/YEL WIRE
HANDLE SW OPEN SIG
HOT AT ALL TIMES
INSTRUMENT CLUSTER
L AJAR SW SIG (1)
LOGIC
MTR RELEASE CTRL
REAR BODY FUSE BLOCK (LEFT SIDE OF LUGGAGE COMPT)
REAR COMPARTMENT LID RELEASE RELAY
RED WIRE
RED/BLU WIRE
SERIAL DATA
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
VIO/GRY WIRE
W/ THEFT DETERRENT SECURITY W/O THEFT DETERRENT SECURITY
YEL/BLU WIRE
Go to component -> Fuel door release circuit -> REAR COMPARTMENT LID RELEASE RELAY
Wiring diagram rear compartment lid release relay (2 of 2)
2.0L 2.0L
2.0L 2.8L
2.8L
BACKUP LAMP SWITCH (M/T)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE
BREAKOUT TO
COOLING FAN MOTOR (W/ SINGLE FAN)
COOLING FAN RELAY
ELECTRONIC BRAKE CONTROL MODULE
ENGINE COMPT) STARTER RELAY
ENGINE COMPT, FORWARD OF BATTERY)
ENGINE CONTROL MODULE
FROM SPLICE
FUEL COMPOSITION SENSOR (2.0L)
HEADLAMP WASHER FLUID PUMP
HEADLAMP WASHER FLUID PUMP RELAY
IGNITION COIL 1
IGNITION COIL 2
IGNITION IGNITION COIL 4 COIL 6
IGNITION MAIN RELAY
MASS AIR FLOW/ INTAKE AIR TEMPERATURE SENSOR (2.0L)
REAR COMPARTMENT LID RELEASE RELAY
REAR DEFOGGER RELAY
RIGHT COOLING FAN MOTOR (W/ DUAL FAN)
SECONDARY AIR INJECTION PUMP
SECONDARY AIR INJECTION PUMP RELAY
SECURITY DOOR LOCK RELAY (IF EQUIPPED)
UNDERHOOD FUSE BLOCK
UNDERHOOD FUSE BLOCK (LEFT SIDE OF
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WINDSHIELD WASHER FLUID LEVEL SENSOR
WINDSHIELD WASHER PUMP
WINDSHIELD WIPER RELAY
WINSHIELD WASHER PUMP RELAY
Go to component -> Ground distribution circuit (2 of 8) -> REAR COMPARTMENT LID RELEASE RELAY
