Saab 9-5 II (2010-2012) driver outside rearview mirror switch Wiring diagram
This page shows the only wiring diagram for the component.driver outside rearview mirror switch, which is found in the car Saab 9-5 II (2010-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver outside rearview mirror switch (1 of 1)
BLK WIRE
BLK/BRN WIRE
BLK/YEL WIRE
BRN/BLK WIRE
BRN/YEL WIRE
COMMON CTRL
DEFOGGER SYSTEM
DOWN
DRIVER OUTSIDE REARVIEW
DRIVER OUTSIDE REARVIEW MIRROR FOLDING MOTOR
DRIVER OUTSIDE REARVIEW MIRROR GLASS
DRIVER OUTSIDE REARVIEW MIRROR SWITCH
FOLDING SWITCH
FUSE
GRY WIRE
GRY/BRN WIRE
GRY/WHT WIRE
HOT W/ IGNITION RELAY ENERGIZED
IGN
INTERCONNECT BUS 8
LEFT
LOGIC
LOW REF
MIRROR DIMMING
MIRROR MOTOR
MIRROR SYSTEM
MOTOR FOLD IN CTRL
MOTOR FOLD OUT CTRL
NCA WIRE
OUTSIDE REARVIEW MIRROR SWITCH
PANEL)
POWER WINDOWS SYSTEM
RED WIRE
RED/GRY WIRE
RIGHT
RT (+) LT (-) CTRL
SEL LEFT
SEL RIGHT
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
UP (+) DOWN (-) CTRL
VIO/BLU WIRE
VIO/RED WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL/BRN WIRE
YEL/WHT WIRE
Go to component -> Memory mirrors circuit (1 of 2) -> DRIVER OUTSIDE REARVIEW MIRROR SWITCH
