Saab 9-5 II (2010-2012) body control night panel module switch Wiring diagram
This page shows the only wiring diagram for the component.body control night panel module switch, which is found in the car Saab 9-5 II (2010-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram body control night panel module switch (1 of 1)
AUXILIARY BLOWER MOTOR CONTROL MODULE
BLK WIRE
BODY CONTROL MODULE
BODY CONTROL NIGHT PANEL MODULE SWITCH
DOOR LOCK AUXILIARY SECURITY POWER RELAY RELAY
DRIVER DOOR COURTESY LAMP
DRIVER DOOR HANDLE ACCENT LAMP
DRIVER DOOR LATCH ASSEMBLY
DRIVER OUTSIDE REARVIEW MIRROR
DRIVER WINDOW MOTOR
DRIVER WINDOW SWITCH
HEAD-UP DISPLAY SWITCH
HEADLAMP DATA LINK SWITCH CONNECTOR
INSTRUMENT PANEL MULTI- FUNCTION SWITCH
LEFT INSTRUMENT PANEL COURTESY LAMP
LEFT REAR DOOR ACCENT LAMP
LEFT REAR DOOR HANDLE ACCENT LAMP
LEFT REAR DOOR LATCH ASSEMBELY
LEFT REAR WINDOW MOTOR
LEFT REAR WINDOW SWITCH
NCA WIRE
OUTSIDE REARVIEW MIRROR SWITCH
RIGHT LOWER INSTRUMENT PANEL ACCENT LAMP
SUNROOF CONTROL MODULE
W/ EXPRESS UP/DOWN
Go to component -> Ground distribution circuit (3 of 8) -> BODY CONTROL NIGHT PANEL MODULE SWITCH
