Saab 9-5 II (2010-2012) 7 10 12 1 5986 2500 2501 5060 data comm enable serial data + serial data - Wiring diagram
This page shows the only wiring diagram for the component.7 10 12 1 5986 2500 2501 5060 data comm enable serial data + serial data -, which is found in the car Saab 9-5 II (2010-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 7 10 12 1 5986 2500 2501 5060 data comm enable serial data + serial data - (1 of 1)
+LAU/LDK
2.0L
2.8L
29 30 6 21 22 25 26 23 24 SERIAL DATA + SERIAL DATA -
6106 6105 5986 2500 2501 SERIAL DATA - SERIAL DATA +
7 10 12 1 5986 2500 2501 5060 DATA COMM ENABLE SERIAL DATA + SERIAL DATA -
BETWEEN BREAKOUT TO LEFT
BLU WIRE
BLU/YEL WIRE
BREAKOUT TO LEFT REAR WHEEL WELL)
DATA COMM ENABLE
DATA COMM ENABLE 2.8L
DATA COMM ENABLE SERIAL DATA + SERIAL DATA -
DK BLU WIRE
GM LAN SER DATA
GRN WIRE
GRN/BRN WIRE
HI SPD GMLAN SERIAL DATA
LAU/ LDK
LAU/ LDK LDK +LAU/
LINEAR
LINEAR LINEAR INTC INTC INTC INTC
PARKING BRAKE CONTROL MODULE
POWER STEERING CONTROL MODULE (IF EQUIPPED) (LOWER LEFT SIDE OF DASH)
REAL TIME DAMPING, W/O AWD
SERIAL DATA (-) SERIAL DATA (+)
SERIAL DATA BUS-
SUSPENSION CONTROL MODULE (IF EQUIPPED) (LEFT SIDE OF LUGGAGE COMPT)
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE (IF EQUIPPED) (CENTER OF DASH)
TO LEFT FRONT DOOR INLINE
TRANSMISSION CONTROL MODULE (TOP OF TRANSMISSION)
W/ AWD W/ CHASSIS CONTINUOUSLY VARIABLE
WHEEL WELL, BETWEEN BREAKOUT TO KEYLESS ENTRY ANTENNA, MAIN BUNDLE)
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Computer data lines circuit (3 of 4) -> 7 10 12 1 5986 2500 2501 5060 DATA COMM ENABLE SERIAL DATA + SERIAL DATA -
