Saab 9-5 II (2010-2012) 17 18 14 data + data - sply volt Wiring diagram
This page shows the only wiring diagram for the component.17 18 14 data + data - sply volt, which is found in the car Saab 9-5 II (2010-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 17 18 14 data + data - sply volt (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 B+ SOL CTRL
1 2 3 4 5 6 SERIAL DATA -
17 18 14 DATA + DATA - SPLY VOLT
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN/GRN WIRE
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
DK BLU/YEL WIRE
DK GRN WIRE
DK GRN/BRN WIRE
DRIVER INFORMATION CENTER DISPLAY
ELECTRONIC BRAKE CONTROL MODULE (LOWER LEFT REAR OF ENGINE COMPT)
FUSE 23
HOT AT ALL TIMES
LOGIC INSTRUMENT CLUSTER
LOW REF
NCA WIRE
POWER STEERING CONTROL MODULE (LOWER LEFT SIDE OF DASH)
RED/YEL WIRE
SERIAL DATA
SERIAL DATA (+) SERIAL DATA (-) SERIAL DATA (+)
SPLY VOLT GROUND
STEERING WHEEL ANGLE SENSOR (ON STEERING COLUMN)
SYSTEM
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
VARIABLE POWER STEERING SOLENOID VALVE (ON STEERING RACK ASSEMBLY)
WHT WIRE
WHT/BLU WIRE
Go to component -> Electronic power steering circuit -> 17 18 14 DATA + DATA - SPLY VOLT
