Saab 9-5 II (2010-2012) 1 1 rf head hi ctrl rf head lo ctrl Wiring diagram
This page shows the only wiring diagram for the component.1 1 rf head hi ctrl rf head lo ctrl, which is found in the car Saab 9-5 II (2010-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 1 1 rf head hi ctrl rf head lo ctrl (1 of 1)
1 1 RF HEAD HI CTRL RF HEAD LO CTRL
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN/ORG WIRE
DK BLU/ORG WIRE
DRV SEAT BELT SW SIG
GRY/ORG WIRE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (FRONT OF CENTER CONSOLE)
LEFT REAR SEAT BELT SWITCH LEFT REAR SEAT BELT BUCKLE
LOW REFR LOW REFR PASS SEAT BELT SW SIG
NCA WIRE
ORG BLK WIRE
ORG/ WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/GRY WIRE
ORG/VIO WIRE
ORG/WHT WIRE
REAR MIDDLE SEAT BELT SWITCH REAR MIDDLE SEAT BELT BUCKLE
RIGHT REAR SEAT BELT SWITCH RIGHT REAR SEAT BELT BUCKLE
RIGHT ROOF RAIL AIR BAG
SHORTING BAR
VIO/ORG WIRE
WHT/ORG WIRE
YEL/ORG WIRE
Go to component -> Supplemental restraints circuit (3 of 3) -> 1 1 RF HEAD HI CTRL RF HEAD LO CTRL
