Wiring diagram engine performance 2.3l turbo for Saab 9-5 I facelift (2001-2005)

AIR CONDITIONING SYSTEM BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BRN/ORG WIRE BRN/RED WIRE BRN/WHT WIRE CLUTCH ACTUATOR UNIT (INTEGRAL TO THROTTLE BODY ) COMPUTER DATA LINES SYSTEM CRANKSHAFT POSITION SENSOR (UNDER EXHAUST MANIFOLD) CRUISE CONTROL SYSTEM DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) DASHBOARD MAIN RELAY BOARD ENGINE BAY MAXI FUSES BOX (NEXT TO BATTERY) FUSE 2 ENGINE MANAGEMENT SYSTEM MAIN RELAY EVAP CANISTER PURGE VALVE (ON HOSE TO MASS AIRFLOW SENSOR) EVAP SHUT-OFF SOLENOID VALVE (NEAR FUEL FILLER PIPE) FUSE 14 FUSE 17 FUSE 39 FUSE 7 GRN/WHT WIRE HOT AT ALL TIMES LIMP-HOME RELAY LIMP-HOME SOLENOID (ON THROTTLE BODY) ORG/ WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/YEL WIRE TRIONIC CONTROL MODULE (OBDII) (RIGHT REAR OF ENGINE COMPT) VIO WIRE WHT WIRE YEL WIRE YEL/GRY WIRE

BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) ENGINE COOLANT TEMPERATURE SENSOR (LEFT END OF CYLINDER HEAD) EVAP PRESSURE SENSOR (ON FUEL TANK, NEAR FUEL PUMP) FUEL PUMP MOTOR (IN FUEL TANK) FUEL PUMP RELAY (ON DASHBOARD MAIN RELAY BOARD) FUSE 15 GRN WIRE GRN/WHT WIRE GRY WIRE GRY/RED WIRE HEATED OXYGEN SENSOR 1 (UPSTREAM OF CATALYTIC CONVERTER) HEATED OXYGEN SENSOR 2 (DOWNSTREAM OF CATALYTIC CONVERTER) IGNITION DISCHARGE MODULE (ON CAMSHAFT COVER) INTAKE AIR TEMPERATURE SENSOR (INTEGRAL WITH CHARGE AIR TEMPERATURE SENSOR) MASS AIRFLOW SENSOR (BEHIND RIGHT HEADLIGHT) ORG/ WIRE ORG/WHT WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/YEL WIRE SPARK PLUG CONNECTORS WHT WIRE WHT/PNK WIRE YEL WIRE YEL/BLU WIRE YEL/GRY WIRE

ABS CONTROL MODULE (BEHIND BATTERY, INTEGRAL TO HYDRAULIC UNIT) BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLU/WHT WIRE BRAKELIGHT SWITCH (ON PEDAL BRACKET) COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM DASHBOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH) FUSE 1 FUEL INJECTOR 1 FUEL INJECTOR 2 FUEL INJECTOR 3 FUEL INJECTOR 4 FUSE 27 GRN WIRE GRN/BLU WIRE GRN/GRY WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT IN OFF, ON OR START ORG/ WIRE ORG/WHT WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/YEL WIRE TRIONIC CONTROL MODULE (OBDII) (BEHIND RIGHT SIDE OF DASH) WHT WIRE WHT/PNK WIRE YEL/BLU WIRE
