Saab 9-5 I facelift (2001-2005) right seat ventilation resistor Wiring diagram
This page shows the only wiring diagram for the component.right seat ventilation resistor, which is found in the car Saab 9-5 I facelift (2001-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right seat ventilation resistor (1 of 1)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
GRN WIRE
GRY WIRE
HOT IN RUN FUSE 32
INTERIOR FUSE BLOCK FUSE (BEHIND LEFT END OF DASH)
LEFT SEAT BACKREST VENTILATION MOTOR
LEFT SEAT VENTILATION RESISTOR
LEFT SEAT VENTILATION SWITCH
ORG/ WIRE
ORG/WHT WIRE
RED WIRE
RIGHT SEAT BACKREST VENTILATION MOTOR
RIGHT SEAT SEAT VENTILATION MOTOR
RIGHT SEAT VENTILATION RESISTOR
RIGHT SEAT VENTILATION SWITCH
VIO WIRE
YEL WIRE
Go to component -> Seat ventilation circuit -> RIGHT SEAT VENTILATION RESISTOR
