Saab 9-5 I facelift (2001-2005) rain sensor relay Wiring diagram
This page shows the only wiring diagram for the component.rain sensor relay, which is found in the car Saab 9-5 I facelift (2001-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rain sensor relay (1 of 1)
5 DOOR
BLK WIRE
BLK/GRN WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
DICE CONTROL MODULE (ABOVE INTERIOR RELAY BLOCK)
FRONT WASHER
FUSE 16
FUSE 37
GRN WIRE
GRN/GRY WIRE
GRN/WHT WIRE
GRNWHT
GRY/WHT WIRE
HEADLAMP HIGH PRESSURE WASHER PUMP
HEADLAMP HIGH PRESSURE WASHER PUMP RELAY (IN UNDERHOOD FUSE/RELAY BOX)
HOT IN
HOT IN RUN OR START
INTERIOR FUSE BLOCK (BEHIND LEFT END OF DASH) FUSE 26
INTERMITTENT WINDSCREEN WIPER RELAY
JR PR
ON OFF II
RAIN SENSOR
RAIN SENSOR RELAY
REAR INTERMITTENT WIPER RELAY (IN UNDERHOOD FUSE/RELAY BOX) (5 DOOR)
REAR WASHER REAR WIPER INTERMITTENT WIPER RHEOSTAT
REAR WINDOW WASHER PUMP WIND- SCREEN WASHER PUMP
REAR WINDOW WIPER MOTOR
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RUN WIRE
UNDERHOOD FUSE/RELAY BLOCK (LEFT REAR OF ENGINE COMPT)
VIO WIRE
WINDSCREEN WIPER MOTOR
WINDSCREEN WIPERS STALK SWITCH
YEL WIRE
YEL/GRN WIRE
Go to component -> Wiper/washer circuit, with rain sensor -> RAIN SENSOR RELAY
