Saab 9-5 I facelift (2001-2005) main instru- ment display Wiring diagram
This page shows the only wiring diagram for the component.main instru- ment display, which is found in the car Saab 9-5 I facelift (2001-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram main instru- ment display (1 of 1)
A/T
AUTOMATIC TRANSMISSION RANGE SWITCH 1 (ON GEAR BOX) IG
BLU WIRE
BRAKE- LIGHTS SWITCH (ON PEDAL BRACKET)
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL BRAKE SWITCH (ON PEDAL BRACKET)
CRUISE CONTROL CLUTCH SWITCH (ON PEDAL BRACKET)
CRUISE CONTROL INDICATOR
FUSE 1
FUSE 21
FUSE 26
FUSE 31
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN
HOT IN RUN OR START
INTERIOR FUSE BLOCK (BEHIND LEFT END OF DASH) FUSE 27
M/T
MAIN INSTRU- MENT DISPLAY
NCA WIRE
ORG/ WIRE
ORG/WHT WIRE
RED WIRE
RES/- CRUISE CONTROL SWITCH
RUN WIRE
SET-
SPEEDO- METER
TRIONIC CONTROL MODULE (RIGHT REAR OF ENGINE COMPT)
VIO WIRE
WHT WIRE
Go to component -> Cruise control circuit -> MAIN INSTRU- MENT DISPLAY
