Saab 9-5 I facelift (2001-2005) left fog lamp Wiring diagrams
This page contains all the electrical diagrams for the component. left fog lamp, in which he is found in the car Saab 9-5 I facelift (2001-2005). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left fog lamp (1 of 2)
54 30 56 OFF PARK HEAD
BATTERY
BLK WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLU WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRN WIRE
DICE CONTROL MODULE (ABOVE INTERIOR RELAY BLOCK)
DIPPED BEAM RELAY (UNDER- HOOD FUSE/ RELAY BLOCK)
EXTERIOR LIGHTS (PARK LAMPS)
EXTERIOR LIGHTS (REAR FOG LAMPS)
FOGLIGHTS RELAY (IN UNDERHOOD FUSE/RELAY BLOCK)
FRONT LAMPS FILAMENT MONITOR (IN UNDERHOOD FUSE/RELAY BLOCK)
FUSE 10 FUSE 11
FUSE 27
FUSE 31
FUSE 35
FUSE 4 FUSE 3
FUSE 7
GRN WIRE
GRN/GRY WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN
HOT IN RUN OR START
IGNITION SWITCH
ILLUM FOG LAMPS SWITCH
INTERIOR FUSE BLOCK (BEHIND LEFT END OF DASH) FUSE 20
INTERIOR LIGHTS
INTERIOR LIGHTS (RHEOSTAT)
LEFT FOG LAMP
LEFT HEADLAMP/ PARKING LAMP ASSEMBLY
LIGHT SWITCH
LIGHTS ON INDICATOR
LOCK
MAIN BEAM INDICATOR
MAIN BEAM RELAY (UNDER- HOOD FUSE/ RELAY BLOCK)
MAIN DIPPED BEAM SWITCH
MAIN INSTRUMENT DISPLAY
MAIN/ DIPPED BEAM LAMP PARKING LAMP
MAXI FUSE 2
ORG/ WIRE
ORG/WHT WIRE
PNK OFF PARK HEAD WIRE
PNK WIRE
REAR FOG LIGHTS SWITCH
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RIGHT FOG LAMP
RIGHT HEADLAMP/ PARKING LAMP ASSEMBLY
RUN WIRE
SAAB INFORMATION DISPLAY (SID) (CENTER OF DASH)
UNDERHOOD FUSE/RELAY BLOCK (AT LEFT REAR CORNER OF ENG COMPT) FUSE 15
UNDERHOOD FUSE/RELAY BLOCK (LEFT REAR CORNER OF ENG COMPT) FUSE 13 FUSE 12
UNDERHOOD MAXI FUSE BLOCK (LEFT REAR OF ENGINE COMPT)
VIO WIRE
WHT WIRE
YEL/BLU WIRE
YEL/WHT WIRE
Go to component -> Headlamps & front fog lamps circuit, without xenon lamps -> LEFT FOG LAMP
Wiring diagram left fog lamp (2 of 2)
BATTERY
BLK WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLU RED/ WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
DICE CONTROL MODULE (ABOVE INTERIOR RELAY BLOCK)
DIPPED BEAM RELAY (UNDER- HOOD FUSE/ RELAY BLOCK)
EXTERIOR LIGHTS (PARK LAMPS)
EXTERIOR LIGHTS (REAR FOG LAMPS)
FOGLIGHTS RELAY (IN UNDERHOOD FUSE/RELAY BLOCK)
FUSE 10 FUSE 11 FUSE 7
FUSE 13 FUSE 12
FUSE 27
FUSE 31
FUSE 35
FUSE 4
FUSE 4 FUSE 3
GRN WIRE
GRN/GRY WIRE
GRN/WHT WIRE
GRY WIRE
HEADLAMP ADJUSTING CIRCUIT
HEADLAMP FLASHER RELAY
HOT AT ALL TIMES
HOT IN
HOT IN RUN OR START
IGNITION SWITCH
ILLUM FOG LAMPS SWITCH
INTERIOR FUSE BLOCK (BEHIND LEFT END OF DASH) FUSE 20
INTERIOR LIGHTS
INTERIOR LIGHTS (RHEOSTAT)
LEFT FOG LAMP
LEFT HEADLAMP/ PARKING LAMP ASSEMBLY
LIGHT SWITCH
LIGHTS ON INDICATOR
LOCK
MAIN BEAM INDICATOR
MAIN BEAM RELAY (UNDER- HOOD FUSE/ RELAY BLOCK)
MAIN DIPPED BEAM SWITCH
MAIN INSTRUMENT DISPLAY
MAXI FUSE 2
OFF 30 56 PARK HEAD
ORG/ WIRE
ORG/WHT WIRE
PARK LAMP
PNK OFF PARK HEAD WIRE
PNK WIRE
REAR FOG LIGHTS SWITCH
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RIGHT FOG LAMP PARK LAMP
RIGHT HEADLAMP/ PARKING LAMP ASSEMBLY
RUN WIRE
SCREEN
UNDERHOOD FUSE/RELAY BLOCK (LEFT REAR CORNER OF ENG COMPT)
UNDERHOOD FUSE/RELAY BLOCK (LEFT REAR CORNER OF ENG COMPT) FUSE 15
UNDERHOOD MAXI FUSE BLOCK (LEFT REAR OF ENGINE COMPT)
VIO WIRE
WHT WIRE
XENON HEAD/ FLASHER LAMP
YEL/BLU WIRE
Go to component -> Headlamps & front fog lamps circuit, with xenon lamps -> LEFT FOG LAMP
