Memory seat circuit for Saab 9-5 I facelift 2 (2005-2010)
Memory seat circuit
1 2 3 4 (PIN 5-17 NOT USED) 18 19 20 21 22 23 24 25 26
BACKWARD
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DASH BOARD MAIN FUSE BOARD (BEHIND LEFT END OF DASH)
DOWN
DRIVER'S SEAT BACKREST ADJUSTMENT POSITION SENSOR/MOTOR
DRIVER'S SEAT FRONT HEIGHT ADJUSTMENT POSITION SENSOR/MOTOR
DRIVER'S SEAT LEGROOM ADJUSTMENT POSITION SENSOR/MOTOR
DRIVER'S SEAT REAR HEIGHT ADJUSTMENT POSITION SENSOR/MOTOR
ELECTRICALLY ADJUSTABLE DRIVER'S SEAT SWITCH
FORWARD/
FUSE 25
FUSE 26
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BRN WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
LAYBACK
MOTOR
ORG/ WIRE
POSITION SENSOR
REAR
RED WIRE
RED/WHT WIRE
UP FRONT
UPRIGHT
VIO/GRN WIRE
WHT WIRE
YEL WIRE
YEL/WHT WIRE
